What is Polyamide?
TPU (thermoplastic polyurethane) or PU is a versatile polymer, made by combining two polymers namely, Polymeric Isocyanate and Polyol. Blending these in unique compositions provides two sub-categories Polyester Polyol based Polyurethane and Polyether Polyol based Polyurethane suitable for production of high quality, flexible tubes and reinforced hose pipes.
Wayhose is tested for
SAEJ844, ISO 7628 & DIN74324
PU Tubes for Industrial and pneumatic applications are made from Polyester based Polyurethane which imparts a High tensile strength to the tube. It is suitable for environments requiring high abrasion resistance such as oil, grease and fuels flow. Industrial PU Tubes are exceptionally capable of bearing compressed air flow.
Available in crystal transparent, colored transparent and opaque finishes with a smooth shiny surface, these tubes are made out of Shore A 90 to 95 hardness.
Wayhose PU Tubes show zero concentricity, lowest ovality in cross section and available in following sizes.
Polyamide 6 Tubes
Code
Size (mm)
Working Pressure
Bursting Pressure
98PU0425
4 x 2.5
10
35
98PU0604
6 x 4
10
35
98PU0805
8 x 5
15
40
98PU0855
8 x 5.5
10
35
98PU0806
8 x 6
7
25
98PU1065
10 x 6.5
15
40
98PU1008
10 x 8
10
35
98PU1208
12 x 8
15
40
98PU1209
12 x 9
10
25
98PU1210
12 x 10
7
20
98PU1612
16 x 12
10
30
*Pressure Rating unit = Bar
Wayhose is tested for
SAEJ844, ISO 7628 & DIN74324
PU Tubes for Industrial and pneumatic applications are made from Polyester based Polyurethane which imparts a High tensile strength to the tube. It is suitable for environments requiring high abrasion resistance such as oil, grease and fuels flow. Industrial PU Tubes are exceptionally capable of bearing compressed air flow.
Available in crystal transparent, colored transparent and opaque finishes with a smooth shiny surface, these tubes are made out of Shore A 90 to 95 hardness.
Wayhose PU Tubes show zero concentricity, lowest ovality in cross section and available in following sizes.
Polyamide 12 Tubes
Code
Size (mm)
Working Pressure
Bursting Pressure
98PU0425
4 x 2.5
10
35
98PU0604
6 x 4
10
35
98PU0805
8 x 5
15
40
98PU0855
8 x 5.5
10
35
98PU0806
8 x 6
7
25
98PU1065
10 x 6.5
15
40
98PU1008
10 x 8
10
35
98PU1208
12 x 8
15
40
98PU1209
12 x 9
10
25
98PU1210
12 x 10
7
20
98PU1612
16 x 12
10
30
*Pressure Rating unit = Bar
Proposed tests for Wayhose
UL 300
Wayhose tubes are non-brittle, long lasting and precisely engineered for easy flow of fire retardants namely Clean Agents (Novec 1230), Gaseous Agents, Dry chemicals, Mechanical Foam and Water Mist.
Made out of Polyamide 12 Nylon Tubes, these tubes are designed to detect and suppress fires quickly, minimizing damage and downtime in the critical areas.
Polyamide 12 Nylon
Code
Size (mm)
Working Pressure
Bursting Temperature
P12A0604
4 x 6
30
110
P12A0806
6 x 8
30
110
*Pressure Rating unit = Bar, Temperature unit = °C
Wayhose is tested for
ISO 11619:2024
PU Tubes for Industrial and pneumatic applications are made from Polyester based Polyurethane which imparts a High tensile strength to the tube. It is suitable for environments requiring high abrasion resistance such as oil, grease and fuels flow. Industrial PU Tubes are exceptionally capable of bearing compressed air flow.
Available in crystal transparent, colored transparent and opaque finishes with a smooth shiny surface, these tubes are made out of Shore A 90 to 95 hardness.
Wayhose PU Tubes show zero concentricity, lowest ovality in cross section and available in following sizes.
Polyamide Tubes
Code
Size (mm)
Working Pressure
Bursting Pressure
98PU0425
4 x 2.5
10
35
98PU0604
6 x 4
10
35
98PU0805
8 x 5
15
40
98PU0855
8 x 5.5
10
35
98PU0806
8 x 6
7
25
98PU1065
10 x 6.5
15
40
98PU1008
10 x 8
10
35
98PU1208
12 x 8
15
40
98PU1209
12 x 9
10
25
98PU1210
12 x 10
7
20
98PU1612
16 x 12
10
30
*Pressure Rating unit = Bar
